3 结论 strain langasite SAWR sensor: temperature compensation
and numerical calibration for direct strain reading[J]. Sen-
本文提出一种桥型 SAW 应变传感器以提高应 sors & Actuators A: Physical, 2017, 259: 34–43.
变灵敏度。结合有限元法和微扰法对桥型 SAW 传 [6] Kalinin V, Leigh A, Nowell A, et al. Strain transfer and
感器不同几何参数下的应变灵敏度进行了分析， creep in all-quartz packaged SAW strain sensors[C]. Inter-
national Frequency Control Symposium, 2018.
结果表明立柱长度和高度对传感器的应变灵敏度 [7] Ren J, Anurakparadorn K, Gu H, et al. Design of
有较大的影响，而立柱宽度对应变灵敏度的影响 SAW sensor for longitudinal strain measurement with
较小。对几何尺寸为 L = 9 mm、W = 13 mm、 improved sensitivity[J]. Microsystem Technologies, 2019,
25(1): 351–359.
T = 0.35 mm、Ta = 0.03 mm 的桥型 SAW 传感器
[8] 马晓倩, 张红梅. 工程力学 [M]. 北京: 中国商务出版社, 2014.
与传统SAW传感器的应变灵敏度进行理论分析，并 [9] 李红浪, 高星, 柯亚兵, 等. 宽温度范围 SAW 应变传感器温度
设计实验对比研究了两种传感器的应变灵敏度。结 与应变解耦研究 [J]. 应用声学, 2018, 37(1): 16–19.
Li Honglang, Gao Xing, Ke Yabing, et al. Study on tem-
果表明，直梁构件受压弯曲时桥型 SAW 传感器的
perature and strain decoupling of SAW strain sensor in
应变灵敏度为 1692 Hz/µε，比传统 SAW 传感器应 wide temperature range[J]. Journal of Applied Acoustics,
变灵敏度提高了 27.41%，为 SAW 应变传感器的高 2018, 37(1): 16–19.
灵敏度受压弯曲应变测量提供新思路。 [10] Hempel J, Finke D, Steiert M, et al. SAW strain sensors-
