第 42 卷 第 4 期                                                                       Vol. 42, No. 4
             2023 年 7 月                          Journal of Applied Acoustics                      July, 2023

             ⋄ 研究报告 ⋄



                                 低温微量超声雾化声学系统                                         ∗





                               陈小静     1   唐 军     1†  肖淼鑫      1    徐镜福     2    白林锋     3



                                              (1 新乡学院机电工程学院       新乡   453003)
                                             (2 南通山口精工机电有限公司        南通  226000)
                                             (3 河南科技学院信息工程学院        新乡  453003)

                摘要:针对低温微量超声雾化声学系统中的关键部件单波长超声雾化喷嘴进行研究。首先基于等效电路原理
                和传输矩阵法分别建立了带中心孔换能器和带中心孔复合变幅杆的频率方程,并应用数学分析软件获得了准
                确的数值解,实现了超声雾化喷嘴的全谐振。然后,对其进行有限元动力学分析和振动特性测试,结果表明二
                者相对于设计频率 25 kHz 的偏差率在 0.6% 以内,且空载超声振幅达 13.5 µm。之后,应用流体仿真分析软件
                对砂轮 -工件磨削区进行流场特性分析,结果表明低温微量超声雾化声学系统可以解决磨削区涡流现象的产
                生。最后,通过对该系统使用前后两种润滑方式的磨削结果进行测试发现:低温微量超声雾化润滑不仅切削液
                使用量少,而且可以避免工件表面出现烧伤和硬度降低。
                关键词:低温微量超声雾化润滑;超声雾化喷嘴;频率方程;有限元分析
                中图法分类号: TH113.1; TB559; O242.21         文献标识码: A          文章编号: 1000-310X(2023)04-0722-08
                DOI: 10.11684/j.issn.1000-310X.2023.04.007


                    Cryogenic minimum quantity ultrasonic atomization acoustic system



                        CHEN Xiaojing  1  TANG Jun  1  XIAO Miaoxin 1  XU Jingfu 2  BAI Lingfeng 3

                      (1 Department of Mechanical and Electrical Engineering, Xinxiang University, Xinxiang 453003, China)
                             (2 Nantong Shankou Jinggong Electromechanical Co., Ltd., Nantong 226000, China)
                     (3 School of Information Engineering, Henan Institute of Science and Technology, Xinxiang 453003, China)

                 Abstract: The single wavelength ultrasonic atomizing nozzle, which is the key component of cryogenic
                 minimum quantity ultrasonic atomization acoustic system, is studied. Firstly, based on the equivalent circuit
                 principle and transmission matrix method, the frequency equations of transducer with central hole and
                 composite horn with central hole are presented. The accurate numerical solution of the frequency equations is
                 obtained by using the mathematical analysis software, and the full resonance of the system is realized. Then,
                 the finite element dynamic analysis and vibration characteristics test of the ultrasonic atomizing nozzle are
                 carried out. The results show that the deviation rate between the two relative to the design frequency 25 kHz
                 is less than 0.6%, and the idle ultrasonic amplitude is 13.5 µm. After that, the flow field characteristics of the
                 grinding area are analyzed by using the fluid simulation analysis software. The results show that the cryogenic
                 minimum quantity ultrasonic atomization acoustic system may solve the generation of air vortex phenomenon


             2022-03-28 收稿; 2022-05-29 定稿
             河南省高等学校重点项目 (21A460022), 河南省科技攻关项目 (202102210113)
             ∗
             作者简介: 陈小静 (1983– ), 女, 河南南阳人, 硕士, 讲师, 研究方向: 精密超精密加工技术及装备。
