检测灵敏度会有所下降。针对该问题，本文在分析 [3] Caccese V, Mewer R, Vel S S. Detection of bolt load loss in
TFM检测超声场模型的基础上，提出充分利用各次 hybrid composite/metal bolted connections[J]. Engineer-
ing Structures, 2004, 26(7): 895–906.
侧壁反射波的检测声场，将能量叠加到初始检测图
[4] Razi P, Esmaeel R A, Taheri F. Improvement of a
像上，达到提高远端灵敏度的目的。以一次反射波 vibration-based damage detection approach for health
的传播路径分析为例，建立了完整的传播声时计算 monitoring of bolted flange joints in pipelines[J]. Struc-
tural Health Monitoring, 2013, 12(3): 207–224.
方法，明确了数值求解的过程。实验结果证明，经多
[5] Sun X, Croxford A J, Drinkwater B W. Continuous moni-
次场能叠加，可以有效提高对微小缺陷的检测能力。 toring with a permanently installed high-resolution ultra-
但也应该注意到，随场能层级累加增加，计算耗时明 sonic phased array[J]. Structural Health Monitoring, 2023,
22(5): 3451–3464.
显增长，同时噪声水平也会相应上升，因此累加场能
[6] Kumar A. Total focusing method-based ultrasonic phased
层级选择要综合考虑。 array imaging in thick structures[J]. Journal of Nonde-
structive Evaluation, Diagnostics and Prognostics of En-
gineering Systems, 2021, 4(4): 041005.
