第 44 卷 第 1 期 Vol. 44, No. 1
2025 年 1 月 Journal of Applied Acoustics January, 2025

⋄ 研究论文 ⋄

相控型圆管换能器产生螺旋声场的仿真与实验分析 ∗

刘乃滔 1,2 杨 娟 1† 许 枫 1

(1 中国科学院声学研究所海洋声学技术实验室 北京 100190)
(2 中国科学院大学 北京 100049)

摘要：声呐系统进行水下导航及目标探测时，需要大规模布阵形成换能器阵列来实现，所需硬件以及信号处理
的复杂度较高。而在螺旋声场中，由于方位角和声压相位角是线性对应的关系，所以仅由一个螺旋信标就能实
现对水下目标的探测。因此，该文设计了一种能够产生螺旋声场的圆管换能器，通过有限元软件仿真，证明了
该圆管换能器可以产生螺旋声场。在此基础上，进行水池实验对螺旋声场的性质进行了验证，为进一步设计出
用于水下导航以及目标探测的声呐系统打下了基础。
关键词：正交偶极子；螺旋声场；相控激励；有限元仿真
中图法分类号: O427.9 文献标识码: A 文章编号: 1000-310X(2025)01-0148-07
DOI: 10.11684/j.issn.1000-310X.2025.01.015

Simulation and experimental analysis of spiral sound field generated
by a phase controlled circular tube transducer

1
LIU Naitao 1,2 , YANG Juan and XU Feng 1
(1 Ocean Acoustic Technology Laboratory, Institute of Acoustics, Chinese Academy of Sciences, Beijing 100190, China)
(2 University of Chinese Academy of Sciences, Beijing 100049, China)

Abstract: When sonar system is used for underwater navigation and target detection, it needs a large scale
array to form a transducer array, which requires high complexity of hardware and signal processing. In the
spiral sound field, because the azimuth angle and the sound pressure phase angle are linearly corresponding,
the underwater target can be detected only by a spiral beacon. Therefore, this paper designs a spiral tube
transducer which can generate spiral sound wave. Through the simulation of finite element software, it is
demonstrated that the spiral tube transducer can generate spiral sound field with high quality. On this basis,
the properties of spiral sound field are verified by pool experiment, which lays a foundation for further designing
sonar system for underwater navigation and target detection.
Keywords: Orthogonal dipole; Spiral sound field; Phase controlled excitation; Finite element simulation

2023-08-24 收稿; 2023-11-03 定稿
海南省重大科技计划项目 (ZDKJ2020010, 62271478)
∗
作者简介: 刘乃滔 (1999– ), 男, 河南焦作人, 硕士研究生, 研究方向: 水声信号处理。
† 通信作者 E-mail: yangjuan@mail.ioa.ac.cn
