704                                                                                  2019 年 7 月


                表 1  随机森林和 SVM 对三类目标的分类结果
                (仿真样本)                                                        参 考 文        献
                Table 1 Random forest and SVM classi-
                fication results for three kinds of targets       [1] Kim S D, Lee J H, Kim J K. A new chain-coding algorithm
                (simulated sample)                                 for binary images using run-length codes[J]. Computer
                                                                   Vision, Graphics, and Image Processing, 1988, 41(1):
                              随机森林     随机森林                        114–128.
                    类别                            SVM
                               (Gini)  (Entropy)                 [2] Belkasim S O, Shridhar M, Ahmadi M. Pattern recog-
                训练集的准确率        96.13%   95.91%  100.00%            nition with moment invariants:  a comparative study
                测试集的准确率        95.50%   94.50%   94.00%            and new results[J]. Pattern Recognition, 1991, 24(12):
                                                                   1117–1138.
                                                                 [3] Barr A H. Superquadrics and angle-preserving transfor-
                表 2  随机森林和 SVM 对三类目标的分类结果
                                                                   mations[J]. IEEE Computer Graphics and Applications,
                (实际样本)                                             1981, 1(1): 11–23.
                Table 2 Random forest and SVM classi-            [4] Pentland A P. Perceptual organization and the repre-
                fication results for three kinds of targets         sentation of natural form[J]. Artificial Intelligence, 1986,
                                                                   28(3): 293–331.
                (actual sample)
                                                                 [5] Peak P. Mathematical games—The superellipse: a curve
                                                                   that lies between the ellipse and the rectangle, scien-
                              随机森林     随机森林
                    类别                            SVM              tific american by martin gardner[J]. Mathematics Teacher,
                               (Gini)  (Entropy)
                                                                   1966, 59(5): 473.
                训练集的准确率        95.27%   94.14%  100.00%
                                                                 [6] 陈京, 袁保宗, 文富荣. 一种基于曲率约束的不完整超二次曲
                测试集的准确率        86.67%   78.57%   80.00%            线拟合 [C]//第十二届全国信号处理学术年会 (CCSP-2005)
                                                                   论文集, 2005: 367–370.
                 从表 2可以看出,对于实际样本,三种分类器的                          [7] Rosin P L. Fitting superellipses[J]. IEEE Transactions
             分类结果均低于仿真样本,由于实际的水下声图像                                on Pattern Analysis & Machine Intelligence, 2000, 22(7):
                                                                   726–732.
             比较复杂,易于受噪声、海底混响等因素的影响,使
                                                                 [8] Ahn S J, Rauh W, Cho S H, et al. Orthogonal distance
             提取的目标阴影边界坐标点与实际的坐标点之间                                 fitting of implicit curves and surfaces[J]. IEEE Transac-
             存在偏差,导致分类准确度下降。尽管分类准确度                                tions on Pattern Analysis & Machine Intelligence, 2002,
                                                                   24(5): 620–638.
             有所下降,但是最高也能达到 86.67%,具有较好的
                                                                 [9] Voss K, Suesse H. A new one-parametric fitting method
             分类效果。                                                 for planar objects[J]. IEEE Transactions on Pattern Anal-
                 通过分析样本集的特征向量,得出产生错分的                              ysis & Machine Intelligence, 1999, 21(7): 646–651.
                                                                [10] Rosin P L, West G A W. Curve segmentation and repre-
             原因主要集中在球体目标和圆台目标之间,当成像
                                                                   sentation by superellipses[J]. IEE Proceedings-Vision, Im-
             设备探测的角度和方位正好处在球体垂直直径位                                 age and Signal Processing, 1995, 142(5): 280–288.
             置上,产生的阴影区域可能与圆台目标的阴影区域                             [11] Fitzgibbon A, Pilu M, Fisher R B. Direct least square fit-
                                                                   ting of ellipses[J]. IEEE Transactions on Pattern Analysis
             相似,导致超椭圆曲线的参数之间区分度不大,从而
                                                                   and Machine Intelligence, 1999, 21(5): 476–480.
             降低分类准确度。                                           [12] Nelder J A, Mead R. A simplex method for function min-
                                                                   imization[J]. Compute Journal, 1965, 7(4): 308–331.
             4 结论                                               [13] Mignotte M, Collet C, Pérez P, et al. Three-class Marko-
                                                                   vian segmentation of high-resolution sonar images[J].
                                                                   Computer Vision and Image Understanding, 1999, 76(3):
                 本文针对水下小目标分类问题,引入了超椭圆
                                                                   191–204.
             曲线拟合算法来识别目标阴影轮廓特性,并将控制                             [14] Kim S D, Lee J H, Kim J K. A new chain-coding algorithm
             曲线形状的 6 个参数 a、b、x、y、θ、ε 作为特征向量输                       for binary images using run-length codes[J]. Computer
                                                                   Vision, Graphics, and Image Processing, 1988, 41(1):
             入到分类器内进行分类。结果表明,a、b、x、y、θ、ε 可
                                                                   114–128.
             以有效地分类出目标所属的类别,因此,超椭圆曲线                            [15] Cutler A, Cutler D R, Stevens J R. Random forests[J].
             拟合算法是一种可行的识别方法。但是,这种方法                                Machine Learning, 2004, 45(1): 157–176.
                                                                [16] Zhao Q, Principe J C. Support vector machines for SAR
             对于极不规则的目标阴影形状识别效果不尽人意,
                                                                   automatic target recognition[J]. IEEE Transactions on
             从而降低分类准确率,仍需要进一步研究与改进。                                Aerospace & Electronic Systems, 2001, 37(2): 643–654.
