少挤压膜阻尼，得到传感单元谐振点处的灵敏度较 scale sandwich composite fuselage panels using acoustic
9
好(1.43 × 10 /(V·m −1 ))； emission[J]. Journal of Composite Materials, 2013, 47(13):
1643–1664.
(3) 在有阻尼状态下，z 方向响应传感单元的谐
[4] Khuri-Yakub B T, Degertekin F L, Jin X, et al. Silicon mi-
振频率为251.11 kHz，在所需响应频段范围内；在无 cromachined ultrasonic transducers[C]//IEEE Ultrasonics
阻尼状态下，z 方向响应传感单元的圆形极板边缘 Symposium, 1998, 2: 985–991.
[5] Jin X, Ladabaum I, Khuri-Yakub B T. The microfabri-
变形量较大且变形量比较均匀。
cation of capacitive ultrasonic transducers[J]. Journal of
通过对x、y 方向响应传感单元的设计和有限元 Microelectromechanical Systems, 1998, 7(3): 295–302.
分析，得到以下结论： [6] Saboonchi H, Ozevin D, Kabir M. MEMS sensor fusion:
acoustic emission and strain[J]. Sensors and Actuators A:
(1) U 型弹簧降低了 x、y 响应传感单元在 z
Physical, 2016, 247: 566–578.
方向上的刚度，传感单元的极板厚度为 60 µm [7] Kabir M, Saboonchi H, Ozevin D. Accurate source local-
时，在 z 方向上获得较小的谐振频率 (146.73 kHz、 ization using highly narrowband and densely populated
197.83 kHz)，相对于在 x、y 方向可以获得较高的谐 mems acoustic emission sensors[C]//Structural Health
Monitoring, 2015.
振频率 (240.5 kHz、234.59 kHz)，有效地将所需 x、
[8] Bekas D G, Sharif-Khodaei Z, Baltzis D, et al. Qual-
y 方向的机械响应与不需要的 z 方向机械响应隔离 ity assessment and damage detection in nanomodified
开来； adhesively-bonded composite joints using inkjet-printed
interdigital sensors[J]. Composite Structures, 2019, 211:
(2) 所研究的 x、y 方向响应传感单元的芯片面
557–563.
积很小 (4.1 mm × 5.3 mm ×1 mm)，灵敏度高、抗 [9] Pollock A A, Stephens R W B. Waveform and frequency
干扰能力强、稳定性好、制造简单。 spectra of acoustic emissions[J]. Journal of the Acoustical
Society of America, 1971, 49(1A): 110.
