第 43 卷 第 1 期 Vol. 43, No. 1
2024 年 1 月 Journal of Applied Acoustics January, 2024

⋄ 研究报告 ⋄

基于改进粒子群算法的超声雾化电源频率跟踪 ∗

胡航溢 1 许 龙 1† 郑伟成 2 罗 凯 2

(1 中国计量大学理学院 杭州 310018)
(2 宁波清大超声科技有限公司 宁波 315300)

摘要：超声波雾化技术由于其良好的雾化效果获得了广泛关注，具有极大的研究价值和应用前景。但是在超
声雾化的过程中，由于换能器的温度变化、刚度变化以及在水中的负载变化等因素，会产生谐振频率漂移的现
象。当工作频率偏移谐振频率时，将造成换能器的工作效率降低和元器件损坏等问题。针对此问题，设计了基
于改进粒子群算法优化 PID 参数的超声雾化电源频率跟踪算法，并对该算法进行频率跟踪的仿真验证和实验
对比，在频率跟踪上实现了更好的效果，使换能器能够稳定工作在谐振状态，提高了电源的利用率。
关键词：超声电源；超声波雾化；频率跟踪；粒子群算法；PID
中图法分类号: TN86 文献标识码: A 文章编号: 1000-310X(2024)01-0198-06
DOI: 10.11684/j.issn.1000-310X.2024.01.023

The frequency tracking of the ultrasonic atomization power supply based on
improved particle swarm optimization

HU Hangyi 1 XU Long 1 ZHENG Weicheng 2 LUO Kai 2

(1 College of Science, China Jiliang University, Hangzhou 310018, China)
(2 Ningbo QDsonic Technology Co., Ltd., Ningbo 315300, China)

Abstract: At present, ultrasonic atomization technology has received extensive attention because of its good
atomization effect, which has great research value and application prospects. However, in the process of
ultrasonic atomization, due to the temperature change, stiffness change of the transducer, load change in water
and other factors, the phenomenon of resonant frequency drift will occur. Once the working frequency is not at
the resonant frequency point, it will reduce the working efficiency of the transducer and damage the electronic
components. To solve this problem, a frequency tracking algorithm of ultrasonic atomization power supply
based on improved particle swarm optimization algorithm to optimize PID parameters is designed. Simulation
and experimental comparison of the algorithm for frequency tracking have been conducted, achieving better
results in frequency tracking, enabling the transducer to work stably in resonant state, and improving the
utilization rate of power supply.
Keywords: Ultrasonic power; Ultrasonic atomization; Frequency tracking; Particle swarm optimization; PID

2022-09-02 收稿; 2022-12-08 定稿
国家自然科学基金项目 (12074354)
∗
作者简介: 胡航溢 (1998– ), 男, 浙江宁波人, 硕士研究生, 研究方向: 超声电源。
† 通信作者 E-mail: xulong250864@163.com
